Stadium LED Display

P10 Stadium LED Display

Stadium LED Display

P16 Stadium LED Display

Applied with special court play software, allows you to manage the scores showing , program playback, Ads showing and the editing of the program list conveniently.

Durable fresh color and High brightness

•Patented design of anti-glare mask with high temperature resistant coating on the surface to absorb direct light, reduce glare, and improve the contrast ratio of display.

•Anti-UV, anti-oxidation module prevents from deformation.

•On-site brightness and chroma calibration can recover the uniformity.

High energy efficiency

•Adopt high-brightness LED with low consumption, saving 20% power energy.

Stability and reliability

•Precise manufacturing process keeps the modules rugged and durable.

•IP65 protection grade, waterproof rubber gasket and military-grade conformal coating enable the display to work in all weather outdoor environments.

•Aircraft-grade connectors of power supply and signal connection are of high reliability, good conductivity and durability, suitable for rapid connection and high frequency use.

•Dual-system and hot swap backup mechanism, improving the reliability of system greatly.

Refresh rate is up to 3600Hz, avoiding screen picture flickering.

Pixel Pitch10mm16mm
LED Configuration1R1G1B DIP3461R1G1B DIP346
Pixel Density10000 dot/m23906 dot/m2
Cabinet Size1280*960mm1024*1024mm
Cabinet Resolution128*96 dot64*64 dot
Cabinet Weight70 KG60 KG
IP Rating(front/back)IP65/IP43IP65/IP43
Brightness≥6500cd/m2≥7000cd/m2
Viewing AngleH110°,V55°H110°,V55°
Gray Scale14bit14bit
Display Scale16.7M16.7M
Max.Power Consumption(W/m2)7501250
Ave.Power Consumption(W/m2)250400
Refresh Rate≥2400≥2400
Operating EnvironmentOutdoor
Operation PowerAC110~220V 50/60HZ
Operating Temperature’-40℃~ 60℃
Operating Humidity10~90% RH
Operating Life100,000 hours
