•Stable and uniform picture Strictly selected LED lamps, high-consistency constant current driving IC, and high-end control system, supporting high refresh rate and ensuring stable picture, high gray scale and high color uniformity.
•Precise module/tile design Promoting the flatness of display surface and ensuring seamless splicing of the tiles.
•Various installations Magnetic assembling, quick assembling with support or common cabinet assembling of the display tiles.
•Serviceability The display can be maintained from the front, back or both for your choice according to the application spot.
Pixel Pitch (mm) | 2.5mm | 3mm | 4mm | 5mm | 6mm | 7.62mm | 10mm |
Pixel density(pix/m2) | 160000 | 111111 | 62500 | 40000 | 27777 | 17222 | 10000 |
LED Type | SMD2121 | SMD2121 | SMD2121 | SMD3528 | SMD3528 | SMD3528 | SMD3528 |
Viewing Angle | H 140°,V140° | H 140°,V140° | H 140°,V140° | H140°,V140° | H140°,V140° | H140°,V140° | H140°,V140° |
Brightness(cd/m2) | 2300 | 1800 | 1500 | 1500 | 1500 | 1500 | 1500 |
Drive Method | 1/32 scan | 1/16 scan | 1/16 scan | 1/16 scan | 1/16 scan | 1/16 scan | 1/8 scan |
Refresh Rate(Hz) | ≥1200HZ | ≥1200HZ | ≥1200HZ | ≥1200HZ | ≥1200HZ | ≥1200HZ | ≥1200HZ |
Module Size (mm) | 160*160mm | 192×96 | 256×128 | 320×160mm | 384*192mm | 244×244mm | 320*160mm |
Cabinet Size(mm) | 480*320mm | 384×384 | 512*512 | 640×640mm | 768*768mm | 732×732mm | 960*960mm |
Voltage | 110/220V | 110/220V | 110/220V | 110/220V | 110/220V | 110/220V | 110/220V |
Average.power(W/m2) | 300 | 360 | 360 | 320 | 300 | 200 | 180 |
Max.power (W/m2) | 750 | 900 | 900 | 800 | 750 | 550 | 450 |
Operating temperature/ humidity | temperature:-20℃~ 50℃ humidity:10~90%RH | ||||||
Storage temperature/ humidity | temperature:-40℃~ 60℃ humidity:10~90%RH | ||||||
Lifetime(h) | ≥100,000 hours | ||||||
MTBF | ≥50,000 hours | ||||||
Protection Ratings | IP31 | ||||||
Control system | Linsn/Nova |
